Project Details

• Length: 53.3 Mtr.

• Width: 7.8 Mtr.

• Height: 7.6 Mtr.

• Total floor area - 4473 Sqft

• Total Project cost per sqft - RS.498.75

❁ Total steel weight - 17 MT

• Column - ISMB 400 (Sail)

• Column to column runner - ISMB 200 (SEL)

• Truss - RHS 122 X61 X 3.6 mm, SHS 72 X 72 X 3.2 mm

• Roof Purlin - RHS 96 X 48 X 3.2 mm

• Vertical purlin - RHS 96 X 48 X 3.2 mm

• Truss bottom runner - RHS 96 X 48 X 3.2 mm

• Column to Truss runner - RHS 96X 48 X 3.2

• Base Plate - 24 mm

• Column connection plate - 10mm

• Truss connection plate - 8 mm

• Stiffener plate - 10 mm​

• Paint + Red-oxide - 80 ltr  (Berger Industrial Paint)

❁ Installation of Bare Galvalume 0.50 mm sheet -  7704 Sqft.

​​

​
